Raymai Transparent LED Screen has the characteristics of ultra-light, ultra-thin and ultra-transparent; frameless appearance is more concise and atmospheric; modular design of product structure, more concise; mainly used in stage rental, hotel theater, commercial center, window, etc. field.
High transparency: the perspective rate is more than 60%
Front lighting (F series) and side lighting (S series), optional
Thin and light: the thickness of the screen body is less than or equal to 60mm, and the weight of a single panel is less than 4kg
Wide viewing angle: 140° viewing angle, covering more viewers
Simple appearance: no border, built-in wiring design
Various installation methods: hoisting, mounting, magnet adsorption, etc.
Pixel | 3.9-7.8mm |
Drving Mode | 7scan |
Module resolution | 126*32dots |
Module Pixel | 4032dots |
Cabinet size(LXH) | 1000*500mm |
Cabinet resolution | 256*64dots |
Transmittance | ≥70% |
Number of modules | 8pcs |
Pixel density | 32256dot/m2 |
Material | Aluminum profile |
Cabinet weight | 7KG |
Brightness | 3000cd/m2 |
Perspective | Horizontal 140°,vertical140° |
Minimum viewing distance | ≥4m |
Gray level | 16bit |
Refresh Rate | >1920HZ |
Frame Frequency | 60fps |
Input voltage | AC 86-264V/60Hz |
Power consumption (max/average) | 800/240W/m2 |
Screen weight | 9.5kg/m2 |
Service life | ≥100,000 HOURS |
IP protection level | IP43 |
Temperature | -20℃~+60℃ or -40℃~+60℃ |
Humidity | 10%-85%RH |
Operating system | NOVA/LINSN |
